MDC / HES Smart-Metering Console

The operator console for a smart-electricity-metering head-end: estate health, alarm triage, live meter reads and guarded remote control, in English and Arabic.

Lead frontend developer · whole console
Cover for MDC / HES Smart-Metering Console

Blurred on purpose: client work under NDA

The operator’s overview: estate availability with online, offline and pending-review meters, alarm pressure over the last 24 hours, the latest meter events with tamper marked, and live health of the API, database and metering engine.

01 / 07

Overview

What it is

MDC / HES is the console a utility’s operators and engineers use to run a fleet of smart electricity meters: estate health, alarm triage, on-demand DLMS reads from a physical meter, and relay and limiter commands that only fire after a confirmation and are judged on the meter’s read-back. I built the frontend almost on my own, on my own Vue component kit, in English and Arabic with dark mode and phone layouts.

A live session on a three-phase meter, terminal skin: voltage and current per phase with sparklines and the change since the last tick, power, frequency on its ruler, the energy registers and the relay, streamed over the device bus. Above it: the meter’s identity, who changed it, and the commanded vs actual relay.

02 / 07

What it does

Live read from a physical meter

A live session on a three-phase meter, terminal skin: voltage and current per phase with sparklines and the change since the last tick, power, frequency on its ruler, the energy registers and the relay, streamed over the device bus. Above it: the meter’s identity, who changed it, and the commanded vs actual relay.

How I built it

DLMS/COSEM in the browser: OBIS catalogue, DLMS date-time codec, unit-aware limiter, a scale guard on bus values

The meter register: counters that follow the filter, server-side search and paging, and each meter’s status, phase, district, concentrator, relay and connectivity.

03 / 07

What it does

The meter register

The meter register: counters that follow the filter, server-side search and paging, and each meter’s status, phase, district, concentrator, relay and connectivity.

How I built it

Server-driven lists with URL-synced filters, summary-fed KPIs and realtime invalidation over WebSocket with an SSE fallback

Alarm triage: the last 24 hours by severity, each event’s level, tamper events marked with a shield, and a Needs attention preset for the critical ones.

04 / 07

What it does

Alarm triage

Alarm triage: the last 24 hours by severity, each event’s level, tamper events marked with a shield, and a Needs attention preset for the critical ones.

How I built it

My own Vue component kit (about 70 components, Vuetify-compatible API) on reka-ui and Tailwind CSS v4

The estate map on MapLibre: meters clustered by the worst state inside (alarm, offline, supply off, online), a legend with counts, and a note on meters with no recorded position. Basemap © OpenStreetMap contributors, OpenFreeMap.

05 / 07

What it does

The estate map

The estate map on MapLibre: meters clustered by the worst state inside (alarm, offline, supply off, online), a legend with counts, and a note on meters with no recorded position. Basemap © OpenStreetMap contributors, OpenFreeMap.

A disconnect the meter accepted but did not carry out: the relay was commanded off and still reads connected, so the page flags it in the state band and in the controls. Disconnect is hold-to-confirm, and the limiter shows its thresholds in the unit the meter reports.

06 / 07

What it does

Guarded remote control

A disconnect the meter accepted but did not carry out: the relay was commanded off and still reads connected, so the page flags it in the state band and in the controls. Disconnect is hold-to-confirm, and the limiter shows its thresholds in the unit the meter reports.

The command log: every relay, limiter and clock command with its result, the server’s read-back of commanded vs confirmed, retries, the device’s response code, and the operator who sent it.

07 / 07

What it does

A command log with read-back

The command log: every relay, limiter and clock command with its result, the server’s read-back of commanded vs confirmed, retries, the device’s response code, and the operator who sent it.
